180 Sample positions.
200 Reagent positions.
160 Reaction cuvettes.
800 Tests / Hour
1. Fully automated, Discrete, Random access,STAT priority,real-time dual wavelength.
2. Total open setting of items, supported different reagents from different countries.
3. Reversed optics and imported photo sensor make sure the precision of detection results.
4. Microsring injector imported from Germany assures the veracity of a trace of samples,
sample step by 0.1 UL, reagent step by0.5 UL
5. 24 hour non-stop working, convenient emergency function with inserting emergency at random.
6. Implementing analysis of ultra-trace reaction solution to 100 UL, and saving more reagents.
7. Discrete cuvette, preventing from cross-infection, and be washed and reused, making sure accurate result and save cost.
8. Perfect self-detection function makes sure the analyzer in order and accurate result.
9. Software is easy to learn and use. And test report can be printed.
10. Perfect function of quality control management is convenient for users to manage the clinical test result.
11. Detecting in the whole reaction process with reaction curve, convenient for users to monitor thoroughly
and scientifically analyze the detection data.
12. Supporting software can implement the function of detecting surplus reagent through liquid level
induction of reagent probe.
Discrete, Fully automatic
800 tests per hour
End-point, Fixed-time, Rate, Turbidimetry
Programmable for any test items
CE, FDA, ISO9001, ISO14001, ISO13485
180 samples, double disk design, including 60 samples for
calibration/quality dribbling refrigerated
Original blood collection tube, micro tube, plastic tube, etc
Serum, plasma, urine, etc
2ul ~70ul (0.1ul stepping)
Having liquid level induction function,
ensuring the accuracy of adding sample
Automatic washing both interior and exterior ,
cross contamination rate < 0.1%
Analyzing maximally 100 items at the same time
200 reagent positions, dual-tray design
Washing solution can be installed in any position, including needle,
stir bar washing solution and water bath disinfectant
20ul~350ul, 0.5ul increment
Continuous 2ºC~8ºC cooling within 24 hours
Having liquid level induction function, ensuring the accuracy of adding
reagent. Inventory checking
Automatic washing both interior and exterior
Water bath,Real-time temperature display
160 positions with permanent hard glass
cuvettes (optical path length 5mm)
Independent stir bar, nanotechnology, highly polished,
automatic frequency conversion
Automatic water cleaning and drying system
System can record the blank value and get more accurate result
by deducting blank base value of each cuvette
Halogen lamp, lamp can be auto sleep and wake up
Holographic flat field concave grating diode array detection
16 wavelengths from 340 to 800nm
< 0.1% or Abs > 3.0
Linear calibration:K factor, two- and multiple linear Nonlinear
Calibration: spline, polynomial, Logarithm, etc
Auto QC,cooled QC positions
Emergency sample can be placed in the sample tray at any time
Windows 7/8/10 or above, LIS system available
Full bi-directional communication possible
Having reaction curve detection and data display function
in the whole process
Deionized water , <45 L/hour
110/220v ±10%, 50/60Hz
