Opportunity to replace 3-diff hematology analyzer
- 5 part differentiation, 27 parameters
- 1 Scattergrams, 4 Histograms
- Up to 90 samples per hour
- Optical solid state LASER scattering
- High efficient light collector (patented)
- 12.1" TFT Touch Screen
- Original reagent, control and calibration
- Easy to operate: Friendly and Intellective Software
- Auto sample for option
Performance
High Stability & Accuracy
l Use the most advanced binuclear embedded digital circuit system, to make the analytical ability great and stable
l 2 counting channels of WBC and RBC, to make the test results more accurate and less cross- contamination
l Use CPLD technology in data processing, to avoid the interference of electromagnetic signals
Reliable Operation System
l ARM intelligent micro-processing technology
l Data analysis: intelligent pulse formulation technology
l Classification: floating landmark technology
l Module design, fast maintenance
User-friendly System
l 10.4''large color LCD displays main menu and all parameters & color histograms in one screen
l Brief operation instruction built-in software, easy for user to view
l Separate module design, very simple mechanical structure, easy maintenance
l Self check for hardware, alarm for error
l Reagent depletion alarm for Lyse, Cleanser and Diluent, as optional function
Technical Features
l 2 counting mode: whole blood, pre-dilution blood
l Sample pre-dilution: internal diluter, add 1ml diluent automatically by the needle, no need to add diluent manually to avoid deviation.
l Calibration: automated or manual
l QC: comprehensive QC program, forming and printing the histogram automatically
l Block removal: Real time monitor, high ignition, soak, flush and back flush
Technical Specifications | |
Principle | Optical solid state LASER scattering Wide angle light scatter,High efficient light collector(patented) Electrical Impedance,Double hydrodynamic focusing |
Parameters | LYM#, Mon#, Neu#, Bas#, Eos#, LYM%, Mon%, Neu%, Bas%, Eos%, Lx, Ly, Nx, Ny, WBC, RBC, Hb, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD*, Plt, Pct, MPV, PDW 1 Scattergrams:WBC/BASO Interpreted Scattergram 4 Histograms:RBC,PLT,WBC,cyto For research only:ACY% , ALY# , LIC% , LIC# , NIL% , NIL# |
Throughput | Up to 90 samples per hour/(Auto sample mode/Open sample mode ≥90samples per hour) |
Sample Volume | Prediluted: 20µL Whole blood: 10µL |
Sample types | Whole blood,PLT only,HB only,Capillary predilution,Diluent,Control,Calibrator |
Display | 12.1Inch Touch Screen |
Storage | Up to 100,000 results including numeric and graphical information |
Printout | External Laser printer/Inkjet printer, various printout formats and user-defined formats |
Carryover | WBC<0.5%, RBC<0.5%, HGB<0.5%, PLT<0.8% |
Mult-language | Chinese,English for optional and others can be customized |
Working Conditions | Temperature: 10-35ºC, Humidity: ≤30%~85% Atmospheric pressure: 70Kpa-106Kpa Power supply: AC100V-240V, 50/60Hz |
Dimension | Instrument:532mmx400mmx520mm Package: 696mmx576mmx696mm |
Weight | Net:28KG Gross:32KG |
